63-ZINA
$ 15.00 USD
| /
Help protect your Max-Prop with a Aluminum Anode. Make sure that you always keep the Anodes in good condition. They must be replaced at least once a year.
The Max-Prop Anode has a metal ring molded into it. This metal ring goes around the entire diameter where the screws attach the Anode to the propeller. This ring disburses the electrical current through the entire Anode giving it a much longer life.
Even with the metal ring PYI recommends when installing the anode that you clean the flat surface of the anode and the back of the propeller so that you will have good contact between the anode and the prop. This will greatly increase the life of the Anode.
We only sell Mil Spec Anodes. Individual Anodes do not come with screws.
It's always a good idea to have spare aluminum anodes on hand, you never know when you need them. We do offer Aluminum Anode Kits which consist of three aluminum anodes and all the necessary screws. This is a great cost effective solution versus buying multiple aluminum anodes individually.
| 63mm and 90mm - HUB DIAMETER | |
| Fits Shaft Diameter |
63mm: 3/4" to 1-1/8" or 22mm to 28mm 90mm: 3/4" to 1-1/4" or 22mm to 30mm |
| Anode Bolt Pattern |
3 bolts with 1.82" or 1.7" center to center on the bolts Each anode has 6 holes to match the two different three hole patterns |
| 70mm and 99mm - HUB DIAMETER |
|
| Fits Shaft Diameter |
70mm: 1-1/8" to 1-3/8" or 30mm to 35mm 99mm: 1-1/4" to 1-1/2" or 30mm to 40mm |
| Anode Bolt Pattern |
3 bolts with 1.97" center to center on the bolts Each anode has 6 holes to match the two different three hole patterns |
| 83mm and 110mm - HUB DIAMETER |
|
| Fits Shaft Diameter |
83mm: 1-1/" to 1-3/4" or 35mm to 45mm 110mm: 1-1/2" to 1-3/4" or 35mm to 45mm |
| Anode Bolt Pattern |
3 bolts with 2.5" or 2.74" center to center on the bolts Each anode has 6 holes to match the two different three hole patterns |
| 100mm - HUB DIAMETER |
|
| Fits Shaft Diameter | 100mm: 1-3/4" to 2" or 45mm to 50mm |
| Anode Bolt Pattern | 3 bolts with 2.875" center to center on the bolts |
| 125mm - HUB DIAMETER | |
| Fits Shaft Diameter | 125mm: 2" to 2-1/2" or 50mm to 68mm |
| Anode Bolt Pattern | 3 bolts with 3.375" center to center on the bolts |
| 126mm - HUB DIAMETER | |
| Fits Shaft Diameter | 126mm: 1-3/4" to 2" or 45mm to 50mm |
| Anode Bolt Pattern | 3 bolts with 2.70" center to center on the bolts |
| 160mm - HUB DIAMETER | |
| Fits Shaft Diameter | 160mm: 3" to 3-1/2" or 68mm to 80mm |
| Anode Bolt Pattern | 3 bolts with 4.45" center to center on the bolts |
